| ItemNo. | Metric | G system | Outer diameter and toterance(mm) | Natural curve(mm) | Max.axial pull(N) | packaging unit(Meter) |
| 规格型号 | 内径 | 英制 | 外径公差 | 自然弯曲半径 | 最大轴向拉力 | 包装米数 |
| YLF-SJSH-6 | Φ6 | 3/16" | 9.00±0.25 | 40 | 335 | 100 |
| YLF-SJSH-8 | Φ8 | 1/4" | 11.8±0.30 | 45 | 470 | 100 |
| YLF-SJSH-10 | Φ10 | 5/16" | 13.3±0.30 | 55 | 590 | 100 |
| YLF-SJSH-12 | Φ12 | --- | 14.9±0.30 | 60 | 710 | 100 |
| YLF-SJSH-13 | Φ13 | 3/8" | 15.9±0.30 | 65 | 765 | 100 |
| YLF-SJSH-15 | Φ15 | --- | 18.1±0.35 | 80 | 885 | 100 |
| YLF-SJSH-16 | Φ16 | 1/2" | 19.1±0.35 | 85 | 940 | 100 |
| YLF-SJSH-19 | Φ19 | --- | 22.9±0.35 | 95 | 1120 | 100 |
| YLF-SJSH-20 | Φ20 | 3/4" | 23.9±0.35 | 100 | 1180 | 100 |
| YLF-SJSH-25 | Φ25 | 1" | 29.5±0.40 | 120 | 1450 | 50 |
| YLF-SJSH-32 | Φ32 | 1-1/4" | 38.7±0.45 | 150 | 1885 | 50 |
| YLF-SJSH-38 | Φ38 | 1-1/2" | 45.2±0.45 | 180 | 2240 | 25 |
| YLF-SJSH-51 | Φ51 | 2" | 57.5±0.50 | 220 | 3000 | 20 |
| YLF-SJSH-64 | Φ64 | 2-1/2" | 73.5±1.50 | 310 | 3770 | 20 |
| YLF-SJSH-75 | Φ75 | 3" | 84.5±2.00 | 350 | 4400 | 20 |
| YLF-SJSH-100 | Φ100 | 4" | 109.0±3.0 | 410 | 4700 | 10 |
| YLF-SJSH-125 | Φ125 | 5" | 135.0±4.0 | 480 | 5100 | 10 |
| YLF-SJSH-150 | Φ150 | 6" | 165±5.0 | 550 | 5600 | 10 |
